DMP Series
-
Delta DMP-300 Series: Mobile Type X X-Ray High-Voltage Generator - DMP-300-50kW
Mobile Type X X-Ray High-Voltage Generator,Max. Output Power:50kW,Input Voltage:40~60VDC(Applicable High-Voltage Generator)/100VAC~240VAC Single-Phase (Applicable Battery Charger),Max. Output Power Rating:500mA/100kV/100ms or 560mA/100kV/20ms,mA Range:10mA~630mA,mAs Range:0.1mAs~630mAs@40kV,Energy Storage Pack Capacity:126mF,Battery:3U-NCM Battery(48V,50Ah),Battery Pack Dimensions:460mm×430mm×120mm,Energy Storage Pack Dimensions:500mm×352mm×150mm,Battery Pack Weight:28.5kg,Energy Storage Pack Weight:18.5kg
$69,642.86
-
Delta DMP-300 Series: Mobile Type X X-Ray High-Voltage Generator - DMP-300-40kW
Mobile Type X X-Ray High-Voltage Generator,Max. Output Power:40kW,Input Voltage:40~60VDC(Applicable High-Voltage Generator)/100VAC~240VAC Single-Phase (Applicable Battery Charger),Max. Output Power Rating:400mA/100kV/125ms,mA Range:10mA~630mA,mAs Range:0.1mAs~630mAs@40kV,Energy Storage Pack Capacity:126mF,Battery:Excl.,Battery Pack Dimensions:460mm×430mm×120mm,Energy Storage Pack Dimensions:500mm×352mm×150mm,Battery Pack Weight:28.5kg,Energy Storage Pack Weight:18.5kg
$58,500.00
-
Delta DMP-300 Series: Mobile Type X X-Ray High-Voltage Generator - DMP-300-32kW
Mobile Type X X-Ray High-Voltage Generator,Max. Output Power:32kW,Input Voltage:40~60VDC(Applicable High-Voltage Generator)/100VAC~240VAC Single-Phase (Applicable Battery Charger),Max. Output Power Rating:320mA/100kV/160ms,mA Range:10mA~630mA,mAs Range:0.1mAs~630mAs@40kV,Energy Storage Pack Capacity:126mF,Battery:Excl.,High-Voltage Generator Dimensions:500mm×352mm×305mm,High-Voltage Generator Weight:22.0kg
$47,142.86
-
Delta DMP-200 Series: Fixed Type X X-Ray High-Voltage Generator (With Capacitor Energy Storage Pack) - DMP-200-40kW
Fixed Type X X-Ray High-Voltage Generator (With Capacitor Energy Storage Pack),Max. Output Power:40kW,Input Voltage:100VAC~240VAC Single-Phase,Max. Output Power Rating:400mA/100kV,mA Range:10mA~500mA,ms Range:1ms~6300ms,Energy Storage Pack Capacity:228mF,High-Voltage Generator Dimensions:630mm×370mm×400mm,Energy Storage Pack Dimensions:503mm×359mm×195mm,High-Voltage Generator Weight:60kg,Energy Storage Pack Weight:25.5kg,Certification:CB
$49,285.71
-
Delta DMP-200 Series: Fixed Type X X-Ray High-Voltage Generator (With Capacitor Energy Storage Pack) - DMP-200-32kW
Fixed Type X X-Ray High-Voltage Generator (With Capacitor Energy Storage Pack),Max. Output Power:32kW,Input Voltage:100VAC~240VAC Single-Phase,Max. Output Power Rating:320mA/100kV,mA Range:10mA~500mA,ms Range:1ms~6300ms,Energy Storage Pack Capacity:60mF,Dimensions:630mm×400mm×370mm,Weight:60kg(Max.),Certification:CB
$40,285.71
-
Delta DMP-100RF Series: Fixed Type X X-Ray High-Voltage Generator - DMP-100RF-82kW
Fixed Type X X-Ray High-Voltage Generator,Type:Dynamic (Supports Single Frame/Pulse/Perspective Mode),Max. Output Power:82kW,Input Voltage:230~277/480VAC±10% Three-Phase,Max. Output Power in Single-Frame Mode:800mA/103kV,mA Range (Single Frame):10mA~1000mA,mAs Range:0.1mAs~1250mAs,Dimensions:654mm×352mm×491mm,Weight:75kg(Max.)
$93,642.86
-
Delta DMP-100RF Series: Fixed Type X X-Ray High-Voltage Generator - DMP-100RF-80kW
Fixed Type X X-Ray High-Voltage Generator,Type:Dynamic (Supports Single Frame/Pulse/Perspective Mode),Max. Output Power:80kW,Input Voltage:230~277/480VAC±10% Three-Phase,Max. Output Power in Single-Frame Mode:800mA/100kV,mA Range (Single Frame):10mA~1000mA,mAs Range:0.1mAs~1250mAs,Dimensions:654mm×352mm×491mm,Weight:75kg(Max.)
$89,142.86
-
Delta DMP-100RF Series: Fixed Type X X-Ray High-Voltage Generator - DMP-100RF-71kW
Fixed Type X X-Ray High-Voltage Generator,Type:Dynamic (Supports Single Frame/Pulse/Perspective Mode),Max. Output Power:71kW,Input Voltage:230~277/480VAC±10% Three-Phase,Max. Output Power in Single-Frame Mode:710mA/100kV,mA Range (Single Frame):10mA~800mA,mAs Range:0.1mAs~1250mAs,Dimensions:654mm×352mm×491mm,Weight:75kg(Max.)
$80,785.71
-
Delta DMP-100RF Series: Fixed Type X X-Ray High-Voltage Generator - DMP-100RF-65kW
Fixed Type X X-Ray High-Voltage Generator,Type:Dynamic (Supports Single Frame/Pulse/Perspective Mode),Max. Output Power:65kW,Input Voltage:230~277/480VAC±10% Three-Phase,Max. Output Power in Single-Frame Mode:800mA/80kV,mA Range (Single Frame):10mA~800mA,mAs Range:0.1mAs~1250mAs,Dimensions:654mm×352mm×491mm,Weight:75kg(Max.)
$72,428.57
-
Delta DMP-100RF Series: Fixed Type X X-Ray High-Voltage Generator - DMP-100RF-56kW
Fixed Type X X-Ray High-Voltage Generator,Type:Dynamic (Supports Single Frame/Pulse/Perspective Mode),Max. Output Power:56kW,Input Voltage:230~277/480VAC±10% Three-Phase,Max. Output Power in Single-Frame Mode:560mA/100kV,mA Range (Single Frame):10mA~800mA,mAs Range:0.1mAs~1250mAs,Dimensions:654mm×352mm×491mm,Weight:75kg(Max.)
$64,071.43
-
Delta DMP-100RF Series: Fixed Type X X-Ray High-Voltage Generator - DMP-100RF-50kW
Fixed Type X X-Ray High-Voltage Generator,Type:Dynamic (Supports Single Frame/Pulse/Perspective Mode),Max. Output Power:50kW,Input Voltage:230~277/480VAC±10% Three-Phase,Max. Output Power in Single-Frame Mode:500mA/100kV,mA Range (Single Frame):10mA~630mA,mAs Range:0.1mAs~1250mAs,Dimensions:654mm×352mm×491mm,Weight:75kg(Max.)
$56,785.71
-
Delta DMP-100RF Series: Fixed Type X X-Ray High-Voltage Generator - DMP-100RF-40kW
Fixed Type X X-Ray High-Voltage Generator,Type:Dynamic (Supports Single Frame/Pulse/Perspective Mode),Max. Output Power:40kW,Input Voltage:230VAC±10% Single-Phase/230~277/480VAC±10% Three-Phase,Max. Output Power in Single-Frame Mode:400mA/100kV,mA Range (Single Frame):10mA~500mA,mAs Range:0.1mAs~630mAs,Dimensions:654mm×352mm×491mm,Weight:75kg(Max.)
$48,000.00
-
Delta DMP-100RF Series: Fixed Type X X-Ray High-Voltage Generator - DMP-100RF-32kW
Fixed Type X X-Ray High-Voltage Generator,Type:Dynamic (Supports Single Frame/Pulse/Perspective Mode),Max. Output Power:32kW,Input Voltage:230VAC±10% Single-Phase/230~277/480VAC±10% Three-Phase,Max. Output Power in Single-Frame Mode:320mA/100kV,mA Range (Single Frame):10mA~400mA,mAs Range:0.1mAs~500mAs,Dimensions:654mm×352mm×491mm,Weight:75kg(Max.)
$42,000.00
-
Delta DMP-100R Series: Fixed Type X X-Ray High-Voltage Generator - DMP-100R-82kW
Fixed Type X X-Ray High-Voltage Generator,Type:Static,Max. Output Power:82kW,Input Voltage:230~277/480VAC±10% Three-Phase,Max. Output Power Rating:800mA/103kV,mA Range:10mA~1000mA,mAs Range:0.1mAs~1250mAs,Dimensions:654mm×352mm×491mm,Weight:75kg(Max.),Certification:CE MDD/CE EMC/CB
$87,857.14
-
Delta DMP-100R Series: Fixed Type X X-Ray High-Voltage Generator - DMP-100R-71kW
Fixed Type X X-Ray High-Voltage Generator,Type:Static,Max. Output Power:71kW,Input Voltage:230~277/480VAC±10% Three-Phase,Max. Output Power Rating:710mA/100kV,mA Range:10mA~800mA,mAs Range:0.1mAs~1250mAs,Dimensions:654mm×352mm×491mm,Weight:75kg(Max.),Certification:CE MDD/CE EMC/CB
$75,214.29
-
Delta DMP-100R Series: Fixed Type X X-Ray High-Voltage Generator - DMP-100R-80kW
Fixed Type X X-Ray High-Voltage Generator,Type:Static,Max. Output Power:80kW,Input Voltage:230~277/480VAC±10% Three-Phase,Max. Output Power Rating:800mA/100kV,mA Range:10mA~1000mA,mAs Range:0.1mAs~1250mAs,Dimensions:654mm×352mm×491mm,Weight:75kg(Max.),Certification:CE MDD/CE EMC/CB
$83,571.43
-
Delta DMP-100R Series: Fixed Type X X-Ray High-Voltage Generator - DMP-100R-65kW
Fixed Type X X-Ray High-Voltage Generator,Type:Static,Max. Output Power:65kW,Input Voltage:230~277/480VAC±10% Three-Phase,Max. Output Power Rating:800mA/80kV,mA Range:10mA~800mA,mAs Range:0.1mAs~1250mAs,Dimensions:654mm×352mm×491mm,Weight:75kg(Max.),Certification:CE MDD/CE EMC/CB
$66,857.14
-
Delta DMP-100R Series: Fixed Type X X-Ray High-Voltage Generator - DMP-100R-56kW
Fixed Type X X-Ray High-Voltage Generator,Type:Static,Max. Output Power:56kW,Input Voltage:230~277/480VAC±10% Three-Phase,Max. Output Power Rating:560mA/100kV,mA Range:10mA~800mA,mAs Range:0.1mAs~1250mAs,Dimensions:654mm×352mm×491mm,Weight:75kg(Max.),Certification:CE MDD/CE EMC/CB
$58,500.00
-
Delta DMP-100R Series: Fixed Type X X-Ray High-Voltage Generator - DMP-100R-40kW
Fixed Type X X-Ray High-Voltage Generator,Type:Static,Max. Output Power:40kW,Input Voltage:230VAC±10% Single-Phase/230~277/480VAC±10% Three-Phase,Max. Output Power Rating:400mA/100kV,mA Range:10mA~500mA,mAs Range:0.1mAs~630mAs,Dimensions:654mm×352mm×491mm,Weight:75kg(Max.),Certification:CE MDD/CE EMC/CB
$43,714.29
